. 80 PLUS® Gold certified efficiency Fully modular cable management Full-bridge LLC converter with DC-to-DC technology Low ripple and tight voltage regulation Model PowerUP 750W Article no. GPX-750FC EAN code 753263077196 Weight (without/with package) 2.3 kg / 2.85 kg AC Input 100 - 240V / 10.0A Frequency 47 - 63Hz +5V 20A +3,3V 20A +5V & +3,3V combined 110W +12V1 62A +12V2 - +12V1, +12V2 combined 744W P.F. -12V 0,3A / 3,6W +5VSB 2,5A / 12,5W Maximum Power 750W 20+4 PIN ATX 1 8 PIN EPS(4+4) 2 8 PIN PCIe (6+2) 4 SATA 9 MOLEX/FLOPPY 3/1 ATX12V Version v2.53 Efficiency 80+Gold Dimension (DxWxH) 140 mm x 150 mm x 86 mm PFC Active PFC Fan 120mm silent fan Security AFC (Automatic Fan speed Control) OCP (Over Current Protection) OPP (Over Power Protection) OTP (Over Temperature Protection) OVP (Over Voltage Protection) SCP (Short Circuit Protection) SIP (Surge & Inrush Protection) UVP (Under Voltage Protection)
